Waste Incineration Treatment Incinerators Avg. 100kgs per hour

HICLOVER incinerator exert the advantages and discard the disadvantages of the same kind of equipment at domestic and abroad. It is an unique and international advanced medical waste incineration equipment. The equipment is small size, high efficiency, reasonable process, leading technologies and a high harmless degree, ideal garbage treatment equipment for hospital, laboratory, hotel, station, etc.

Items/Model TS100(PLC)

Principle Waste Incineration Treatment
Burn Rate Average 100 kg/hour
Feed Capacity Average 200kg/feeding
Control Mode PLC(Programmable Logic Controller Incinerator)
Combustion Chamber 1200L
Internal Dimensions 120x100x100cm
Secondary Chamber 600L
Smoke Filter Chamber Yes(Dry Scrubber)
Feed Mode Manual
Voltage 220V
Power 0.7Kw
Oil Consumption (kg/hour) average 20.4
Gas Consumption (m3/hour) average 24.5
Temperature Monitor Digital Display
Temperature Protection Yes
Oil Tank 200L
Feed Door 80x60cm
Chimney 10Meter
Chimney Type Stainless Steel
1st. Chamber Temperature 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃
Residency Time 2.0 Sec.
Gross Weight 6000kg
External Dimensions 260x150x180cm
