Presently, we supply different series for local customer requirements and design updated incinerator with our leading technology. The updated design feature of our range of incinerators make them one of the most cost effective in the world.
Key Features:
* All models with Dual combustion chamber.
* Stainless Steel chimney/stack, long lifetime.
* High temperature, long lifetime of incinerator.
* Free or minimum installation on site.
* High burn rate, from 10kgs to 600kgs per hour, up to 10ton per day.
* PLC Control Plane for Intelligent operation.
* New Design for pet animal cremation business.
* One year warranty on incinerator and parts in stock.
WWW.HICLOVER.COM｜Waste Incinerators ｜Auto Roll Air Filters
Nanjing Clover Medical Technology Co.,Ltd.
Tel: +86-25-8461 0201
Mobile: +86-13813931455(whatsapp/wechat)
Website: www.hiclover.com
Email: sales@hiclover.com
Email: hicloversales@gmail.com
| Items/Model | TS10(PLC) | TS20(PLC) | TS30(PLC) | TS50(PLC) | TS100(PLC) |
| Burn Rate (Average) | 10 kg/hour | 20 kg/hour | 30 kg/hour | 50 kg/hour | 100 kg/hour |
| Feed Capacity(Average) | 20kg | 40kg | 60kg | 100kg | 200 kg |
| Control Mode | PLC | PLC | PLC | PLC | PLC |
| Combustion Chamber | 100L | 210L | 330L | 560L | 1200L |
| Internal Dimensions | 50x50x40cm | 65x65x50cm | 75x75x60cm | 100x80x70cm | 120x100x100cm |
| Secondary Chamber | 50L | 110L | 180L | 280L | 600L |
| Smoke Filter Chamber | Yes | Yes | Yes | Yes | Yes |
| Feed Mode | Manual | Manual | Manual | Manual | Manual |
| Voltage | 220V | 220V | 220V | 220V | 220V |
| Power | 0.5Kw | 0.5Kw | 0.5Kw | 0.7Kw | 0.7Kw |
| Oil Consumption (kg/hour) | 5.4–12.6 | 7.8–16.3 | 10.2–20 | 12.1–24 | 14–28 |
| Gas Consumption (m3/hour) | 6.2–11.4 | 8–15.7 | 9.8–20 | 9.9–26.1 | 10–32.2 |
| Temperature Monitor | Yes | Yes | Yes | Yes | Yes |
| Temperature Protection | Yes | Yes | Yes | Yes | Yes |
| Oil Tank | 100L | 100L | 100L | 100L | 200L |
| Feed Door | 30x30cm | 45x40cm | 55x50cm | 70x55cm | 80x60cm |
| Chimney | 3Meter | 3Meter | 5Meter | 5Meter | 10Meter |
| Chimney Type | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| 1st. Chamber Temperature | 800℃–1000℃ | 800℃–1000℃ | 800℃–1000℃ | 800℃–1000℃ | 800℃–1000℃ |
| 2nd. Chamber Temperature | 1000℃-1200℃ | 1000℃-1200℃ | 1000℃-1200℃ | 1000℃-1200℃ | 1000℃-1200℃ |
| Residency Time | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. |
| Gross Weight | 1500kg | 2200kg | 3000kg | 4500kg | 6000kg |
| External Dimensions | 140x90x120cm | 160x110x130cm | 175x120x140cm | 230x130x155cm | 260x150x180cm |
Mobile Containerized Incinerator Units to properly incinerate Solid Waste, Petroleum Oil, and Lubricants. Each Unit will be in accordance
to the technical specifications/ operational capacity as defined below. Additionally, each Unit will provide Operation Manuals and Training
Material.PROCESS AT LEAST 1 METRIC TON OF WASTE PER DAY
OPERABLE BY 1 PERSON, WITH NO TRAINING REQUIRED
REGULAR MAINTENANCE CAN BE COMPLETED BY 1 PERSON WITH LIMITED TRAINING
REGULAR MAINTENANCE SHOULD NOT EXCEED 1-HOUR PER DAY
COMPLIES WITH EURO / OR US-EPA EMISSION STANDARDS
ABILITY TO INCINERATE WASTE PETROLEUM, OILS, AND LUBRICANTS
TEMPRATURES DURING THE COMBUTION PROCESS MUST EXCEED 1,500 °F FOR AT LEAST 1-HOUR
CAN BE TRANSPORTED TO AND FROM DEPLOYMENT LOCATION IN A 20-FOOT OR SMALLER SHIPPING ISO CONTAINER
CAPABLE OF 24 HOURS OF CONTINUOUS USE
AUTOMATIC LOADING SYSTEM
AUTOMATED ASH REMOVAL SYSTEM
GAS SCRUBBING SYSTEM
95% REDUCTION OF SOLID WASTE
OPERABLE WITH DIESEL, JP8, OR FUEL OIL
CAPABLE OF BURNING 4 UNITS OF WASTE PER UNIT OF FUEL
ABLE TO INCINERATE COMBUSTIBLE WASTE TO INCLUDE: PAPER, PLASTIC, CARDBOARD, FOOD, USED OILS, SLUDGE, OILY RAGS, AND WOOD PALLETS.
NO PRE-TREATMENT OF WASTE REQUIRED
VENDOR REPAIR OFFERED AT POINT OF SHIPMENT
FIVE (5) YEAR COMPONENT WARRANTY FROM DATE OF ACCEPTANCE Technical Specifications
OPERATION MANUAL AND TRAINING MANUAL FOR EACH INCINERATOR PROVIDED AS PART OF BID PACKAGE
SET UP AND INSTALLATION INSTRUCTION MANUALS PROVIDED AS PART OF BID PACKAGE
BLUE PRINT/ SCHEMATIC PROVIDED THAT OUTLINES THE PHYSICAL DIMENSIONS OF THE 20-FOOT CONTAINERIZED INCINERATORS
DELIVERY PLAN TO EXPLAIN THE MOVEMENT OF 20-FOOT INCINERATORS FROM POINT OF ORIGIN TO CAMP ARIFJAN, KUWAIT
MOBILITY PLAN TO EXPLAIN HOW TO MOVE 20-FOOT INCINERATORS FROM BASE TO BASE WITHIN US ARMY CENTRAL COMMAND THEATRE
INCINERATORS COMPOSED WITH HEAVY DUTY WELDED CONSTRUCTION
EACH INDIVIDUAL UNIT OPERATED AND TRANSPORTED IN A 20-FOOT ISO SHIPPING CONTAINER
