HICLOVER Top Feeding Door Waste Incinerators
***Primary Combustion Chamber
***Secondary Combustion Chamber
***Smoke Filter Chamber
***Optional Wet Scrubber System(1 section or 3 sections)
▲▲▲Large Feeding Door
▲▲▲Better for Animal Waste Cremation
▲▲▲HICLOVER Brand Section
Phone: +86-13813931455(whatsapp/wechat)
Website: http://www.hiclover.com/
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.
Phone: +86-13813931455(whatsapp/wechat)
Website: http://www.hiclover.com/
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.
Phone: +86-13813931455(whatsapp/wechat)
Website: http://www.hiclover.com/
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.
Phone: +86-13813931455(whatsapp/wechat)
Website: http://www.hiclover.com/
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.
Phone: +86-13813931455(whatsapp/wechat)
Website: http://www.hiclover.com/
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.
● Double Combustion Chambers
All waste incinerator design with double combustion chamber. High Temperature, Smoke Treatment，No black smoke, Environmentally friendly.
● Containerized Mobile Incinerators
The incinerator mounted in ISO Container before leave factory, free-installation, no incineration house build construction,movable by truck.
● Family Pets Dog&Cat Cremation
Special design with movable platform, combustion chamber material and custom made for pets crematory business.
● Installation and Commissioning
Clover’s engineers install,train for most of the region and free-cost train in our factory.
| Items/Model | TS100(PLC) | TS150(PLC) | TS300(PLC) | TS500(PLC) |
| Burn Rate (Average) | 100 kg/hour | 150 kg/hour | 300 kg/hour | 500 kg/hour |
| Control Mode | PLC Auto. | PLC Auto. | PLC Auto. | PLC Auto. |
| Combustion Chamber | 1200L | 1500L | 2000L | 3000L |
| Internal Dimensions | 120x100x100cm | 150x100x100cm | 170x120x100cm | 210x120x120cm |
| Secondary Chamber | 600L | 750L | 1000L | 1500L |
| Smoke Filter Chamber | Dry Scrubber | Dry Scrubber | Dry Scrubber | Dry Scrubber |
| Feed Mode | Manual | Manual | Manual | Manual |
| Voltage | 220V | 220V | 220V | 220V |
| Power | 1.38Kw | 1.69Kw | 2.57Kw | 4.88Kw |
| Diesel Oil Consumption (kg/hour) | Ave.20.4 | Ave.24.2 | Ave.33 | Ave.44 |
| Natural Gas Consumption (m3n/hour) | Ave.24.5 | Ave.29 | Ave.39.6 | Ave.52.8 |
| Temperature Monitor | Yes | Yes | Yes | Yes |
| Temperature Protection | Yes | Yes | Yes | Yes |
| Oil Tank | 200L | 300L | 500L | 500L |
| Smoke Wet Scrubbers | Optional | Optional | Optional | Optional |
| Chimney | 10Meter | 10Meter | 14Meter | 14Meter |
| Chimney Type | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| 1st. Chamber Temperature | 800℃–1000℃ | 800℃–1000℃ | 800℃–1000℃ | 800℃–1000℃ |
| 2nd. Chamber Temperature | 1000℃-1200℃ | 1000℃-1200℃ | 1000℃-1200℃ | 1000℃-1200℃ |
| Residency Time | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. |
| Gross Weight | 6000kg | 8500kg | 11000kg | 16000kg |
| External Dimensions | 260x150x180cm | 300x160x190cm | 400x210x300cm | 450x210x300cm |
hospital incinerator ash
HICLOVER Solution for Fighting COVID-19, Medical Waste Incinerator
2020-07-28
Phone: +86-13813931455(whatsapp/wechat)
Website: http://www.hiclover.com/
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.
| Items/Model | TS20(PLC) |
| Picture |
|
| Principle | Medical Waste Incineration |
| Burn Rate | Average 20 kg/hour |
| Feed Capacity | Average 40kg/feeding |
| Control Mode | PLC(Programmable Logic Controller Incinerator) |
| Combustion Chamber | 210L |
| Internal Dimensions | 65x65x50cm |
| Secondary Chamber | 110L |
| Smoke Filter | Wet Scrubber (Water Spary tower) |
| Feed Mode | Manual |
| Voltage | 380V |
| Power | 5Kw |
| Oil Consumption (kg/hour) | 7.8–16.3 |
| Gas Consumption (m3/hour) | 8–15.7 |
| Temperature Monitor | Digital Display |
| Temperature Protection | Yes |
| Oil Tank | 100L |
| Feed Door | 45x40cm |
| Chimney | 5Meter |
| Chimney Type | Stainless Steel |
| 1st. Chamber Temperature | 800℃–1000℃ |
| 2nd. Chamber Temperature | 1000℃-1200℃ |
| Residency Time | 2.0 Sec. |
| Gross Weight | 4000kg |
| External Dimensions | 160x110x130cm(Incinerator) |
HICLOVER Solution for Fighting COVID-19, Medical Waste Incinerator
2020-07-28
Phone: +86-13813931455(whatsapp/wechat)
Website: http://www.hiclover.com/
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.
Capacity: Average 300 kgs per hour
Model YD-300 Picture
Burning Rate Average 300 kgs/hour Feed Capacity Average 500 kgs/feeding Primary Combustion Chamber 2400 Liters Secondary Combustion Chamber 1200 Liters Mix Combustion Chamber Yes Smoke Filter Chamber Wet Scrubber System(3 Section Type) Feed Mode Manual Voltage 380V Power 12.0 Kw Fuel Type Diesel Oil/ Natural Gas/LPG Burner Italy Original Oil Consumption (Diesel Oil) Average 33kg/hour Gas Consumption (Natural Gas) *** Internal Dimensions 220 x 110 x 100cm (primary chamber) External Dimensions 260 x 220 x 420cm (without chimney/wet scrubber) Temperature Monitor Yes Oil Tank Capacity(if oil fuel) 500 Liters Door Opening 90 x 110cm Chimney Length 10.0 Meters Chimney Type Stainless Steel Equipment Gross Weight 14000 kgs Operation Technical Specifications Primary Chamber Temperature 800℃–1000℃ Secondary Chamber Temperature 1000℃-1200℃ Residency Time 2.0 Sec. Burning Efficiency ＞98% Waste Lower Calorific Power 3000Kcal
Pathological waste: organs, tissues, surgical specimens, bodily fluids removed during surgery or autopsy.
HICLOVER Solution for Fighting COVID-19, Medical Waste Incinerator
2020-07-27
Phone: +86-13813931455(whatsapp/wechat)
Website: http://www.hiclover.com/
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.
Capacity: Average 300 kgs per hour
Model YD-300 Picture Burning Rate Average 300 kgs/hour Feed Capacity Average 500 kgs/feeding Primary Combustion Chamber 2400 Liters Secondary Combustion Chamber 1200 Liters Mix Combustion Chamber Yes Smoke Filter Chamber Wet Scrubber System(3 Section Type) Feed Mode Manual Voltage 380V Power 12.0 Kw Fuel Type Diesel Oil/ Natural Gas/LPG Burner Italy Original Oil Consumption (Diesel Oil) Average 33kg/hour Gas Consumption (Natural Gas) *** Internal Dimensions 220 x 110 x 100cm (primary chamber) External Dimensions 260 x 220 x 420cm (without chimney/wet scrubber) Temperature Monitor Yes Oil Tank Capacity(if oil fuel) 500 Liters Door Opening 90 x 110cm Chimney Length 10.0 Meters Chimney Type Stainless Steel Equipment Gross Weight 14000 kgs Operation Technical Specifications Primary Chamber Temperature 800℃–1000℃ Secondary Chamber Temperature 1000℃-1200℃ Residency Time 2.0 Sec. Burning Efficiency ＞98% Waste Lower Calorific Power 3000Kcal
Pathological waste: organs, tissues, surgical specimens, bodily fluids removed during surgery or autopsy.
HICLOVER Solution for Fighting COVID-19, Medical Waste Incinerator
2020-07-27
Phone: +86-13813931455(whatsapp/wechat)
Website: http://www.hiclover.com/
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.
Capacity: Average 300 kgs per hour
Model YD-300 Picture Burning Rate Average 300 kgs/hour Feed Capacity Average 500 kgs/feeding Primary Combustion Chamber 2400 Liters Secondary Combustion Chamber 1200 Liters Mix Combustion Chamber Yes Smoke Filter Chamber Wet Scrubber System(3 Section Type) Feed Mode Manual Voltage 380V Power 12.0 Kw Fuel Type Diesel Oil/ Natural Gas/LPG Burner Italy Original Oil Consumption (Diesel Oil) Average 33kg/hour Gas Consumption (Natural Gas) *** Internal Dimensions 220 x 110 x 100cm (primary chamber) External Dimensions 260 x 220 x 420cm (without chimney/wet scrubber) Temperature Monitor Yes Oil Tank Capacity(if oil fuel) 500 Liters Door Opening 90 x 110cm Chimney Length 10.0 Meters Chimney Type Stainless Steel Equipment Gross Weight 14000 kgs Operation Technical Specifications Primary Chamber Temperature 800℃–1000℃ Secondary Chamber Temperature 1000℃-1200℃ Residency Time 2.0 Sec. Burning Efficiency ＞98% Waste Lower Calorific Power 3000Kcal
Pathological waste: organs, tissues, surgical specimens, bodily fluids removed during surgery or autopsy.
HICLOVER Solution for Fighting COVID-19, Medical Waste Incinerator
2020-07-27
HICLOVER Solution for Fighting COVID-19, Medical Waste Incinerator
Tel: +86-25-8461 0201
Mobile: +86-13813931455(whatsapp/wechat)
Website: http://www.hiclover.com/
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.
| Item | Serie No. | Part Name |
| Packing List | 1# | Incinerator Mainbody |
| 2# | Oil Tank(Deposit) | |
| 3# | Oil Tank(Daily) | |
| 4# | Chimney(Vertical,High Temperature) | |
| 5# | Chimney(Horizontal,High Temperature) | |
| 6# | Wet Scrubber | |
| 7# | Chimney(S shape) | |
| 8# | Chimney(Below) | |
| 9# | Chimney(Top) |
Hospital Incinerators for Medical Waste Destruction
| SN | Item | Specification |
| 1 | Model | TS100 |
| 2 | Burning Rate | Ave.50-100Kgs/Hour |
| 3 | Feeding Capacity | Ave.200Kgs/Feeding |
| 4 | Primary Chamber | 1000 Liters |
| 5 | Secondary Chamber | 540 Liters |
| 6 | Chimney | Yes |
| 7 | Wet Scrubber | Yes |
| 8 | Wet Scrubber Parameter | Dia. 100cm Hight 2500cm |
| 9 | Feeding Model | Manual |
| 10 | Power | 380V 3P 50Hz |
| 11 | Power | 6.0 Kw |
| 12 | Fuel Type | Diesel Oil |
| 13 | Burner | Italy |
| 14 | Oil Consumption (Diesel Oil) | Average 20.4 Kgs/Hour |
| 15 | Internal Dimensions Primary Chamber | 120 x 100 x 90 cm |
| 16 | External Dimensions (Main Body) | 270 x 190 x 170cm |
| 17 | Temperature Monitor | Yes |
| 18 | Oil Tank (Daily) | 1.8M3 |
| 19 | Oil Tank(Deposit) Parameter | 10M3, Dia. 200cm Length 3500cm |
| 20 | Feeding Door | 80 x 60cm |
| 21 | Chimney | 6.0 M |
| 22 | Chimney Material | S.Steel |
| 23 | Weight | Ave.8500Kgs |
| 24 | 1st. Chamber Temperature | 800℃–1000℃ |
| 25 | 2nd. Chamber Temperature | 1000℃-1200℃ |
| 26 | Residency Time | 2Sec. |
2020-07-27
