Dual heat burners and dual chamber incinerator Burning capacity up to 30 Kg per hour with wet scrubber

Dual heat burners and dual chamber incinerator Burning capacity up to 30 Kg per hour
Main Product List

Primary Combustion Chamber(Main body stainless steel)
Secondary Combustion Chamber(Main body stainless steel)
Mix-Combustion Chamber
Wet Scrubber( Washing Tower)(Main body stainless steel)
Incinerator Control Case
Chimney:5.0Meters Stainless Steel
Italy gas burner: 02 sets
Oil Tank (if oil fuel): 100Liters

Model YD-30C Feed Capacity Average 50 kgs per feeding Burning Rate Average 30 kgs per hour Burning Time per Feed 2 hours Voltage 380V Power 6 Kw Fuel Natural Gas Burner Italy Burner Feed Mode Manual Fuel consumption (Oil) 10.2-20.0 Kgs/Hour Fuel consumption (Gas) 12.2-24.0m3/Hour External Dimensions 170 x 140 x 190cm (main body) Internal Dimensions 55 x 55 x 85cm(Primary Chamber) Waste combustion chamber 250Liters Post Combustion Chamber 140Liters Oil Tank Capacity 100 Liters Door Opening 38 x 48cm Chimney 5.0M Gross Weight 3300kgs Chamber Material Refractory Concrete Max. Heat Value 200,000Kcal/Hr. Operation Technical Specifications Solid Chamber temperature 8000C -10000C Gas Chamber temperature 10000C -12000C Chamber Anti-Rate 13500C Residency time 2.0 Sec. Burning efficiency ＞98% Waste Lower Calorific Power 3000Kcal

Dual heat burners and dual chamber incinerator Burning capacity up to 30 Kg per hour with wet scrubber

Dual heat burners and dual chamber incinerator Burning capacity up to 30 Kg per hour
Main Product List

Primary Combustion Chamber(Main body stainless steel)
Secondary Combustion Chamber(Main body stainless steel)
Mix-Combustion Chamber
Wet Scrubber( Washing Tower)(Main body stainless steel)
Incinerator Control Case
Chimney:5.0Meters Stainless Steel
Italy gas burner: 02 sets
Oil Tank (if oil fuel): 100Liters

Model YD-30C Feed Capacity Average 50 kgs per feeding Burning Rate Average 30 kgs per hour Burning Time per Feed 2 hours Voltage 380V Power 6 Kw Fuel Natural Gas Burner Italy Burner Feed Mode Manual Fuel consumption (Oil) 10.2-20.0 Kgs/Hour Fuel consumption (Gas) 12.2-24.0m3/Hour External Dimensions 170 x 140 x 190cm (main body) Internal Dimensions 55 x 55 x 85cm(Primary Chamber) Waste combustion chamber 250Liters Post Combustion Chamber 140Liters Oil Tank Capacity 100 Liters Door Opening 38 x 48cm Chimney 5.0M Gross Weight 3300kgs Chamber Material Refractory Concrete Max. Heat Value 200,000Kcal/Hr. Operation Technical Specifications Solid Chamber temperature 8000C -10000C Gas Chamber temperature 10000C -12000C Chamber Anti-Rate 13500C Residency time 2.0 Sec. Burning efficiency ＞98% Waste Lower Calorific Power 3000Kcal

Medical Waste Incinerator Capacity Average 100kgs per hour

Temperature Display & PLC Control Case

Primary Combustion Chamber

Incinerator Main Body

Italy Oil/Gas Burner

***Primary Combustion Chamber
***Secondary Combustion Chamber
***Smoke Filter Chamber***Chimney:10.0Meters

***Incinerator PLC Control Case***Italy oil/gas burner: 02 units
***Oil Tank (if oil fuel): 200Liters

Items/Model TS100(PLC)
Principle Waste Incineration Treatment
Burn Rate Average 100 kg/hour
Feed Capacity Average 200kg/feeding
Control Mode PLC(Programmable Logic Controller Incinerator)
Combustion Chamber 1200L
Internal Dimensions 120x100x100cm
Secondary Chamber 600L
Smoke Filter Chamber Yes(Dry Scrubber)
Feed Mode Manual
Voltage 220V
Power 0.7Kw
Oil Consumption (kg/hour) 14–28
Gas Consumption (m3/hour) 10–32.2
Temperature Monitor Digital Display
Temperature Protection Yes
Oil Tank 200L
Feed Door 80x60cm
Chimney 10Meter
Chimney Type Stainless Steel
1st. Chamber Temperature 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃
Residency Time 2.0 Sec.
Gross Weight 6000kg
External Dimensions 260x150x180cm

Medical Waste Incinerator Capacity Average 100kgs per hour

Temperature Display & PLC Control Case

Primary Combustion Chamber

Incinerator Main Body

Italy Oil/Gas Burner

***Primary Combustion Chamber
***Secondary Combustion Chamber
***Smoke Filter Chamber***Chimney:10.0Meters

***Incinerator PLC Control Case***Italy oil/gas burner: 02 units
***Oil Tank (if oil fuel): 200Liters

Items/Model TS100(PLC)
Principle Waste Incineration Treatment
Burn Rate Average 100 kg/hour
Feed Capacity Average 200kg/feeding
Control Mode PLC(Programmable Logic Controller Incinerator)
Combustion Chamber 1200L
Internal Dimensions 120x100x100cm
Secondary Chamber 600L
Smoke Filter Chamber Yes(Dry Scrubber)
Feed Mode Manual
Voltage 220V
Power 0.7Kw
Oil Consumption (kg/hour) 14–28
Gas Consumption (m3/hour) 10–32.2
Temperature Monitor Digital Display
Temperature Protection Yes
Oil Tank 200L
Feed Door 80x60cm
Chimney 10Meter
Chimney Type Stainless Steel
1st. Chamber Temperature 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃
Residency Time 2.0 Sec.
Gross Weight 6000kg
External Dimensions 260x150x180cm

Containerized Mobile Incinerator Model CA50

Waste Incinerator

(Containerized Mobile Incinerator)

Capacity: Average 50 kgs per hour

Model CA50
Internal Dimensions 100 x 80 x 70 cm
Main Product List Primary Combustion Chamber
Secondary Combustion Chamber
Smoke Filter Chamber
Incinerator Control Case
Chimney:5.0Meters

*(upgrade to Stainless Steel, free cost)
Italy oil/gas burner: 02 units
Oil Tank (if oil fuel): 200Liters
ISO 20′ Container(Delivery with Incinerator)

Containerized Mobile Incinerator Model CA50

Waste Incinerator

(Containerized Mobile Incinerator)

Capacity: Average 50 kgs per hour

Model CA50
Internal Dimensions 100 x 80 x 70 cm
Main Product List Primary Combustion Chamber
Secondary Combustion Chamber
Smoke Filter Chamber
Incinerator Control Case
Chimney:5.0Meters

*(upgrade to Stainless Steel, free cost)
Italy oil/gas burner: 02 units
Oil Tank (if oil fuel): 200Liters
ISO 20′ Container(Delivery with Incinerator)

Model TS30 oil fired waste small incinerator 30kgs

Model TS30 oil fired waste small incinerator 30kgs/hr.

Items/Model TS30(PLC)

Burn Rate Average 20-30 kg/hour
Feed Capacity Average 60kg per feeding
Control Mode PLC(Programmable Logic Controller Incinerator)
Combustion Chamber 330L
Internal Dimensions 75x75x60cm
Secondary Chamber 180L
Smoke Filter Chamber Yes
Feed Mode Manual Feeding
Voltage 220V
Power 0.5Kw
Oil Consumption (kg/hour) Average 13.3
Gas Consumption (N.G, m3n/Hour) Average 16
Gas Consumption (L.P.G, m3n/Hour) Average 11.7
Temperature Monitor Four Digital Display
Temperature Protection Yes
Oil Tank 100L or More(Optional)
Feed Door 55x50cm
Chimney 5Meter or More(Optional)
Chimney Type Stainless Steel
1st. Chamber Temperature 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃
Residency Time 2.0 Sec.
Gross Weight 4000kg
External Dimensions 175x120x140cm

Model TS30 oil fired waste small incinerator 30kgs

Model TS30 oil fired waste small incinerator 30kgs/hr.

Items/Model TS30(PLC)

Burn Rate Average 20-30 kg/hour
Feed Capacity Average 60kg per feeding
Control Mode PLC(Programmable Logic Controller Incinerator)
Combustion Chamber 330L
Internal Dimensions 75x75x60cm
Secondary Chamber 180L
Smoke Filter Chamber Yes
Feed Mode Manual Feeding
Voltage 220V
Power 0.5Kw
Oil Consumption (kg/hour) Average 13.3
Gas Consumption (N.G, m3n/Hour) Average 16
Gas Consumption (L.P.G, m3n/Hour) Average 11.7
Temperature Monitor Four Digital Display
Temperature Protection Yes
Oil Tank 100L or More(Optional)
Feed Door 55x50cm
Chimney 5Meter or More(Optional)
Chimney Type Stainless Steel
1st. Chamber Temperature 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃
Residency Time 2.0 Sec.
Gross Weight 4000kg
External Dimensions 175x120x140cm
