Model	A1500 (customer made model)
Internal Dimensions	150 x 100 x 96cm
Suit for Animal	Cat – yes	Dog – yes	Pig – yes	Cow – no
Main Product List	Primary Combustion Chamber
	Secondary Combustion Chamber
	Mix-Combustion Chamber
	Wet Scrubber( WashingTower)(Optional Part)
	Incinerator Control Case
	Chimney:10.0Meters *(upgrade to Stainless Steel, free cost)
	Italy oil burner: 03 sets
	Oil Tank : 500Liters

Optional Part	Movable platform & Auto. Door and Independent air supply system at bottom

Burning Rate	Average 100 kgs/hour
Feed Capacity	Average 150 kgs/feeding
Primary Combustion Chamber	1500 Liters
Secondary Combustion Chamber	500 Liters
Mix Combustion Chamber	Yes
Smoke Filter Chamber	Yes(Wet Scrubber) (optional)
Feed Mode	Manual
Voltage	380V
Fuel Type	Diesel Oil
Burner	Italy Original
Oil Consumption (Diesel Oil)	Average 53 kg/hour
Gas Consumption (Natural Gas)	***
Internal Dimensions	150 x 100 x 96cm (primary chamber)
External Dimensions	240 x 170 x 380cm (without chimney)
Temperature Monitor	Yes
Oil Tank Capacity(if oil fuel)	500 Liters
Door Opening	90 x 80cm
Chimney Length	10.0 Meters
Chimney Type	Stainless Steel
Equipment Gross Weight	9000 kgs

Main Product List		Primary Combustion Chamber
		Secondary Combustion Chamber
		Mix-Combustion Chamber
		Smoke Filter Chamber
		Incinerator Control Case
		Chimney:5.0Meters *(upgrade to Stainless Steel, free cost)
		Italy oil burner: 02 sets
		Oil Tank: 150Liters
		Mobile Trailer for Incinerator

Main Product List		Primary Combustion Chamber
		Secondary Combustion Chamber
		Mix-Combustion Chamber
		Smoke Filter Chamber
		Incinerator Control Case
		Chimney:5.0Meters *(upgrade to Stainless Steel, free cost)
		Italy oil burner: 02 sets
		Oil Tank: 150Liters
		Mobile Trailer for Incinerator

We finish this project in year 2010 to 2011 and delivery to Hochiminh port, Vietnam with 1×40’feet open top full container.

We finish this project in year 2010 to 2011 and delivery to Hochiminh port, Vietnam with 1×40’feet open top full container.

There are 03 sets Model YD-100 delivery to Iraq between year 2013 to 2014. The incinerator use for local several construction sites and all fuel type is diesel oil.

There are 03 sets Model YD-100 delivery to Iraq between year 2013 to 2014. The incinerator use for local several construction sites and all fuel type is diesel oil.

Incinerator Model YD-30 for Australia Melbourne customer. From year 2011 to 2013, we delivery 02 different model for this customer, one is model SYC-50 (now updated to Model TS50 PLC) and one model YD-30. Both two model is gas fuel type and these incinerator for local family pet cremation business.

Incinerator Model YD-30 for Australia Melbourne customer. From year 2011 to 2013, we delivery 02 different model for this customer, one is model SYC-50 (now updated to Model TS50 PLC) and one model YD-30. Both two model is gas fuel type and these incinerator for local family pet cremation business.

50kgs per hour incinerator with two chambers suppliers from china

*Aveage 50kgs per hour
*Double chamber and double burner
*900liters primary combustion chamber
*Italy burner
*Stainless steel chimney

Model	YD-50
Burning Rate	Average 50 kgs/hour
Feed Capacity	Average 150 kgs
Primary Combustion Chamber	900 Liters
Secondary Combustion Chamber	300 Liters
Mix Combustion Chamber	Yes
Smoke Filter Chamber	Yes
Feed Mode	Manual
Voltage	220V/380V
Power	0.7Kw
Fuel Type	Diesel Oil/ Natural Gas/LPG
Burner	Italy Original
Oil Consumption (Diesel Oil)	12.1–23.9 kg/hour
Gas Consumption (Natural Gas)	9.9–26.1 m3/hour
Internal Dimensions	120 x 90 x 85cm (primary chamber)
External Dimensions	200 x 160 x 310cm (without chimney)
Temperature Monitor	Yes
Oil Tank Capacity(if oil fuel)	300 Liters
Door Opening	62 x 80cm
Chimney Length	5.0 Meters
Chimney Type	Stainless Steel
Equipment Gross Weight	5500 kgs
Operation Technical Specifications
Primary Chamber Temperature	800℃–1000℃
Secondary Chamber Temperature	1000℃-1200℃
Residency Time	2.0 Sec.
Burning Efficiency	＞98%
Waste Lower Calorific Power	3000Kcal
