Product Description

Principle of the Incinerator equipment is incineration/combustion/burn.

Items/Model TS100(PLC)
Burn Rate 100 kg/hour
Feed Capacity 200 kg
Control Mode PLC
Combustion Chamber 1200L
Internal Dimensions 120x100x100cm
Secondary Chamber 600L
Smoke Filter Chamber Yes
Feed Mode Manual
Voltage 220V
Power 0.7Kw
Oil Consumption (kg/hour) 14–28
Gas Consumption (m3/hour) 10–32.2
Temperature Monitor Yes
Temperature Protection Yes
Oil Tank 200L
Feed Door 80x60cm
Chimney 10Meter
Chimney Type Stainless Steel
1st. Chamber Temperature 800 degree –1000 degree
2nd. Chamber Temperature 1000 degree -1200degree
Residency Time 2.0 Sec.
Gross Weight 6000kg
External Dimensions 260x150x180cm


Considering Environmental Protection requirements and rules, just about all incinerator have secondary combustion chamber (after-burn, post-combustion), even when third combustion chamber. The secondary burner burn the Exhaust gas from main combustion chamber, this technology make sure adequate combustion, few black smoke and smell.  The updated incinerator technology focus on Exhaust gas treatment to eliminate Hazardous material and other function from incinerator, like heat recovery (waste to energy), save fuel cost, PLC Automation performance.  In certain Developed countries, some new waste treatment method such as High-temperature cooking, waste carbonization, crushing sterilization technology is rather than incineration technology.

Suministro de Inclinadores para Proyecto de Terminal Nacional de Llegada Provisional

Servicios CMC para inclinadores durante 3 años, incluidos todos los repuestos, consumibles, mano de obra calificada, herramientas y aparejos, todo completo. Según el alcance adjunto como anexo
Diseño, fabricación, suministro, entrega al sitio, instalación, prueba y puesta en servicio de todos los inclinadores de pasajeros resistentes a la intemperie de acuerdo con el alcance y las especificaciones generales mencionadas en el anexo.
 Incinerador Spesifikasi 100 kg / mermelada

Material de Spesifikasi dan Daftar

Capacidad de potencia dimensional

Nama Barang : INCINERADOR
Tipo / Modelo : PWR-INC-KMN 10
Kapasitas: 100kg / Mermelada (1 m3)
Largo : 288 cm
Ancho : 147 cm
Altura : 163 cm
Altura de la chimenea estándar: 700 cm
PESO TOTAL: 8000 kg
Panel – temporizador : Alarma automática digital incluida
Refinamiento : Pintura resistente al calor
Depósito de combustible : 200 litros
Elemento de revestimiento de acero: 3-8 mm
Quemador Banyaknya: 2 piezas
Soplador Banyaknya : 2 piezas
Max. Consumo de combustible: 15-30 litros / mermelada
Max. Consumo eléctrico : 1100 vatios
Bahan bakar : Queroseno / Diesel (solar)
Voltaje : 220 V / 1 fase / 50 Hz

Material

1. CONTROL DE PANEL

Tipo: digital
Buatan: KAMINE local (Panel dan Incinerator satu Merek)
Voltaje: 220 V / 1 fase / 50 Hz
Operador de seguridad: parada de emergencia
Sistema: Microcontrolador
Pengoperasiano: semiautomático
Control de temperatura: Tipo de acoplador digital
Panel de control : Manual y automático
Tipe : Tipo autoportante / Tipo montado en la pared
Material : Acero dulce
Termocontrol : 2 (Dua) 1200 ºC
Conjunto de temporizador : 0-2 mermelada
Saklar de Tombol : encendido apagado

2. CONTRUCCIONES

Ladrillo de fuego : SK 34
Castable: R 16
Moldeable : R 14
Aislador : Ladrillo aislante serat tahan panas Keramik 1.450 ⁰ C
Elemento de acero : 3-8 mm
Refinamiento : Revestimiento Cat Fetalit, Resina epoxi (pintura resistente al calor)
Berat keseluruhan total: 8.000 kg
Ketebalan Dinding Dalam: 21 cm

3.DIMENSIÓN DE LA CÁMARA (Dimensi Ruang Bakar)

Cámara 1 Ruang Bakar Utama: 100 x 100 x 98 cm = 980.000 cm3 = 0,98 m3
Cámara 2 Ruang Bakar Kedua: 40 x 100 x 98 cm = 392.000 cm3 = 0.39 m3

4. PILA DE ESCAPE (Chimenea)
– Diámetro (pulgadas): Ø 10 ″, 8 ″
-Panjang: 700 cm (7 m) dari permukaan tanah
-Cerobong pertama dengan system Cor tipe MWHT
-Material Acero dulce (Baja Hitam)

5. INSTRUMENTACIÓN Y CONTROL
1. Control de Suhu: Óptimo
– Modelo: Digital
– Jumlah (unidad): 2 (dua) unidad
– Modo Kontrol: encendido-apagado
2. Fuente de alimentación (voltios / fase / herts): 15A / 220 V / 1 fase / 50 Hz
3. Panel kandang: acero dulce + recubrimiento en polvo
4. Termopar: K
– Jumlah: 2 (dua) unidad
– Bahan: acero inoxidable + cerámica
5. Temporizador: 0-2 Jam
6. Eliminación de cenizas: manual
7. Sistema pembuangan Abu 2 unidad
6. PINTU
Pintu: Baja ringan dan Linning dengan castable
Sistema: sistema de doble bloqueo (penguncian ganda)

7. SISTEMA DE SUMINISTRO DE AIRE
Modelo / Tipo: ventilador sentrifugal 3 ”
Kapasitas (m3 / minuto): 3.000 m3 / mnt
Estadística Tekanan (mmAq): 98 mmAq
Potencia: 200 vatios / unidad
Jumlah (unidad): 2 (dua)

8. SISTEMA DE COMBUSTIBLE
Quemador Pembakaran:
Tipo: tipo de pistola OM 2N
Bahan Bakar: aceite diesel / queroseno
Konsumsi Bahan Bakar: 10-18 litros / mermelada
Potencia: 250 vatios
Unidad Jumlah: 1 unidad

Tipo: tipo de pistola OM 2N
Bahan Bakar: aceite diesel / queroseno
Konsumsi Bahan Bakar: 10-18 litros / mermelada
Potencia: 250 vatios
Unidad Jumlah: 1 unidad

9. TERMOCOPIO
Ruang bakar pertama dan kedua
Tipe : K
Tubo protector : Acero inoxidable + cerámica
Max. temperatura : 1200 ºC
Jumlah : 2 unidad
Sistem pemberian umpan : Manual
Sistem pengeluaran hasil : Manual

10. TANGKI BAHAN BAKAR
Material : Acero dulce
Kapasitas : 200 litros

 Autoclave horizontal 155 litros
Cámara de esterilización: calentada por vapor a través de una pared trasera doble con generador de vapor integrado
Puerta y cerradura: puerta batiente con cerradura rápida y cerradura de seguridad
 Sello de la puerta: diseño de escape, cierre uniforme, retorno automático sin sistema de vacío
Tecnología de medición de temperatura: 2 sensores independientes para controlar el generador de vapor + 1 sensor para la cámara de esterilización
 Tecla de precalentamiento
 El interruptor de llave de seguridad guarda la configuración del programa
Indicadores de la fase de esterilización
 Suministro de aire a presión: Compresor integrado para circuito de control de puerta y válvulas de ajuste neumático
 Consumo de agua de alimentación por lote de 0,7 a 5,6 litros
Consumo de agua de refrigeración por lote para condensador de vapor gastado de 10 a 25 la temperatura de 15 ° C
 Control de nivel de agua: dentro de la pared trasera doble
 Fusible de seguridad de bajo nivel de agua: monitor de sobrecalentamiento del calentador
 Ventilación estéril: Filtro de membrana 0,2um, 0,1 m² hidrófobo, esterilizable con vapor, retención 99,5%
 Circuitos de control: separados para el calentador y el sello de la puerta, control y monitoreo del proceso
 El programa del temporizador comienza por fecha y hora
Alarma acústica seleccionable al final del programa
Dispositivo de seguridad de transporte para puerta.
Tres recipientes aptos para autoclave (polipropileno o acero inoxidable) 5-10L

Medium sized incinerator

Medical Waste Incinerator for Coronavirus Disease( COVID-19).

* Full variety incinerator with Standard Small-Large Scale incinerator, General Municipal Solid Waste Incinerator, Containerized Mobile Incinerator, High Efficient Environmental Waste Incinerator.
* Single burning chamber, double combustion chambers, three combustion chambers and also multi-combustion chambers waste incinerators.
* System solutions for clinical waste environmental.
* High burnning price, from 5kgs to 1000kgs per hour.
* HICLOVER, relied on partner with years of experience. incineration of medical waste,incinerators municipal waste

Items/Model

TS30(PLC)


Brand/Code

HICLOVER/N994

Burn Rate

Average 30 kg/hour

Feed Capacity

Average 60kg per feeding

Control Mode

PLC(Programmable Logic Controller Incinerator)

Combustion Chamber

330L

Internal Dimensions

75x75x60cm

Secondary Chamber

180L

Smoke Filter Chamber

Yes

Feed Mode

Manual Feeding

Voltage

220V

Power

0.5Kw

Oil Consumption (kg/hour)

Average 13.3

Gas Consumption (N.G, m3n/Hour)

Average 16

Gas Consumption (L.P.G, m3n/Hour)

Average 11.7

Temperature Monitor

Four Digital Display

Temperature Protection

Yes

Oil Tank

200L

Feed Door

55x50cm

Chimney

5Meter

Chimney Type

Stainless Steel

1st. Chamber Temperature

800℃–1000℃

2nd. Chamber Temperature

1000℃-1200℃

Residency Time

2.0 Sec.

Gross Weight

3000kg

External Dimensions

175x120x140cm

tenders of incienerator,incineration waste recovery

HICLOVER Solution for Fighting COVID-19, with ISO9001:2015/CE(2006/42/EC,2014/30/EU) Certification.
1. Medical Waste Incinerator(Containerized Mobile Incinerator｜Top Loading Incinerator)
2. Auto Roll Air Filter for Clean Room(Air Purification)

Nanjing Clover Medical Technology Co.,Ltd.
Tel: +86-25-8461 0201
Mobile: +86-138139 31455
WhatsApp: 008613813931455
WhatsApp: 008615380948599
Twitter ID: @hiclovercom
Wechat: 008613813931455 (ID: hiclovercom)
Wechat: +8615380948599 (ID: wasteincinerator)

Website1: www.hiclover.com
Website2: www.clover-incinerator.com
Email1: [email protected]
Email2: [email protected]
Email3: [email protected]
Email4: [email protected]

HICLOVER Incinerator/Parts Range Main Feature
Medical Waste Incinerators HICLOVER 10-500kgs/Hr.Double Combustion Chambers
Single Combustion Chamber Small, Cheap,10-20kgs/Hr.
Three Combustion Chambers(Optional) 3 Chambers for high risk waste
Pet Cremation Equipment For Pet(small/big) Cremation Business
Animal Incineration Equipment For other animal incineration
Items/Model TS10(PLC) TS20(PLC) TS30(PLC) TS50(PLC)
Brand HICLOVER HICLOVER HICLOVER HICLOVER
Burn Rate (Average) 10 kg/hour 20 kg/hour 30 kg/hour 50 kg/hour
Feed Capacity(Average) 20kg 40kg 60kg 100kg
Control Mode PLC PLC PLC PLC
Combustion Chamber 100L 210L 330L 560L
Internal Dimensions 50x50x40cm 65x65x50cm 75x75x60cm 100x80x70cm
Secondary Chamber 50L 110L 180L 280L
Smoke Filter Chamber Yes Yes Yes Yes
Feed Mode Manual Manual Manual Manual
Voltage 220V 220V 220V 220V
Power 0.5Kw 0.5Kw 0.5Kw 0.7Kw
Oil Consumption (kg/hour) 5.4–12.6 7.8–16.3 10.2–20 12.1–24
Gas Consumption (m3/hour) 6.2–11.4 8–15.7 9.8–20 9.9–26.1
Temperature Monitor Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes
Oil Tank 100L 100L 100L 100L
Feed Door 30x30cm 45x40cm 55x50cm 70x55cm
Chimney 3Meter 3Meter 5Meter 5Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800℃–1000℃ 800℃–1000℃ 800℃–1000℃ 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 1500kg 2200kg 3000kg 4500kg
External Dimensions 140x90x120cm 160x110x130cm 175x120x140cm 230x130x155cm
Items/Model TS100(PLC) TS150(PLC) TS300(PLC) TS500(PLC)
Burn Rate (Average) 100 kg/hour 150 kg/hour 300 kg/hour 500 kg/hour
Control Mode PLC Auto. PLC Auto. PLC Auto. PLC Auto.
Combustion Chamber 1200L 1500L 2000L 3000L
Internal Dimensions 120x100x100cm 150x100x100cm 170x120x100cm 210x120x120cm
Secondary Chamber 600L 750L 1000L 1500L
Smoke Filter Chamber Dry Scrubber Dry Scrubber Dry Scrubber Dry Scrubber
Feed Mode Manual Manual Manual Manual
Voltage 220V 220V 220V 220V
Power 1.38Kw 1.69Kw 2.57Kw 4.88Kw
Diesel Oil Consumption (kg/hour) Ave.20.4 Ave.24.2 Ave.33 Ave.44
Natural Gas Consumption (m3n/hour) Ave.24.5 Ave.29 Ave.39.6 Ave.52.8
Temperature Monitor Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes
Oil Tank 200L 300L 500L 500L
Chimney 10Meter 10Meter 14Meter 14Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800℃–1000℃ 800℃–1000℃ 800℃–1000℃ 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 6000kg 8500kg 11000kg 16000kg
External Dimensions 260x150x180cm 300x160x190cm 400x210x300cm 450x210x300cm

CE and ISO Certification Pass Incinerators

2021-03-02

Medical Waste Incinerator for Coronavirus Disease( COVID-19)

Medical Waste Incinerator for Coronavirus Disease( COVID-19).

* Full variety incinerator with Standard Small-Large Scale incinerator, General Municipal Solid Waste Incinerator, Containerized Mobile Incinerator, High Efficient Environmental Waste Incinerator.
* Single combustion chamber, dual burning chambers, three burning chambers and also multi-combustion chambers waste incinerators.
* System services for clinical waste ecological.
* High burnning rate, from 5kgs to 1000kgs per hour.
* HICLOVER, trusted companion with years of experience.

We are Waste Incinerator Manufacturer in China. We produce medical waste incinerators, family pet animal cremation devices as well as othe solid waste incinerators. The burning rate from 10kgs,20 kgs,30 kgs,50 kgs,100 kgs,150 kgs,200 kgs,300 kgs,500 kgs,600 kgs per hour, the everyday therapy capability up to 6ton per day.
Clover Incinerators made all dual combustion chamber, Italy initial oil or burner. We make use of stainless steel smokeshaft for our incinerator with lengthy lifetime. For clean exhaust, we provide completely dry or damp scrubber with benefit technology.
Incinerator market as well as customers are all over the globe and also have neighborhood supplier supply direct solution.
Nanjing Clover Medical Technology Co., Ltd. is a leading waste incinerator supplier in China. All series consisted of melting capacity 10kgs per hr, 30kgs per hour,50 kgs per hour,100 kgs per hour,150 kgs per hour,300 kgs per hr,500 kgs per hr.
Regular version incinerator for market with burning price from 10kgs to 500kgs per hr and we constantly proposal customer send us their require details, like waste product, neighborhood site fuel as well as power supply, incinerator operation time, etc, so we can proposition right model or custom made with various structure or measurements.
Incinerator Model YD-100 is a middle scale incineration maker for various use: for a middle health center sickbed below 500 systems, for all huge or small dimension family members pets (like Alaskan Malamute Dog), for area Municipal Solid Waste Incineration, and so on. The key combustion chamber quantity is 1200Liters (1.2 m3) and also utilize diesel oil or gas fuel heater original from Italy.
All our incinerator use stainless steel chimney, not steel.All our incinerator have 2 combustion chamber at least, not single chamber. All gas burner from Italy made with renowned brand name, highest quality.
300kgs per hour burning rate incinerator is well liked by market because this version can be clinical waste incineration equipment for big healthcare facility as well as also excellent for various other solid waste treatment with cheapest cost, even if large size animals additionally can be feed right into the burning chamber. The main burning chamber quantity is 2.4 m3, large enough for typical size animals. For delivering transport, YD-300 can be packed into 40’feet complete high container.
Huge size burning chamber approximately 4.0 m3 as well as Internal Dimensions is 257 x 147 x 108cm with feeding door opening up 108 x 128cm. This model can be a small waste incineration factory with little quantity of budget funds. If end customer use this for ranch to melt pets like cow, equine or camel, contact with us currently.

We produce medical waste incinerators, pet dog animal cremation devices and othe strong waste incinerators. The burning price from 10kgs,20 kgs,30 kgs,50 kgs,100 kgs,150 kgs,200 kgs,300 kgs,500 kgs,600 kgs per hr, the everyday treatment capacity up to 6ton per day.
All collection consisted of burning capacity 10kgs per hour, 30kgs per hr,50 kgs per hr,100 kgs per hour,150 kgs per hr,300 kgs per hr,500 kgs per hr. 300kgs per hr burning rate incinerator is well suched as by market because this model can be medical waste incineration tools for big healthcare facility as well as likewise very good for other strong waste treatment with lowest expense, also if huge size pets additionally can be feed into the burning chamber.

HICLOVER Solution for Fighting COVID-19, with ISO9001:2015/CE(2006/42/EC,2014/30/EU) Certification.
1. Medical Waste Incinerator(Containerized Mobile Incinerator｜Top Loading Incinerator)
2. Auto Roll Air Filter for Clean Room(Air Purification)

Nanjing Clover Medical Technology Co.,Ltd.
Tel: +86-25-8461 0201
Mobile: +86-138139 31455
WhatsApp: 008613813931455
WhatsApp: 008615380948599
Twitter ID: @hiclovercom
Wechat: 008613813931455 (ID: hiclovercom)
Wechat: +8615380948599 (ID: wasteincinerator)

Website1: www.hiclover.com
Website2: www.clover-incinerator.com
Email1: [email protected]
Email2: [email protected]
Email3: [email protected]
Email4: [email protected]

HICLOVER Incinerator/Parts Range Main Feature
Medical Waste Incinerators HICLOVER 10-500kgs/Hr.Double Combustion Chambers
Single Combustion Chamber Small, Cheap,10-20kgs/Hr.
Three Combustion Chambers(Optional) 3 Chambers for high risk waste
Pet Cremation Equipment For Pet(small/big) Cremation Business
Animal Incineration Equipment For other animal incineration
Items/Model TS10(PLC) TS20(PLC) TS30(PLC) TS50(PLC)
Brand HICLOVER HICLOVER HICLOVER HICLOVER
Burn Rate (Average) 10 kg/hour 20 kg/hour 30 kg/hour 50 kg/hour
Feed Capacity(Average) 20kg 40kg 60kg 100kg
Control Mode PLC PLC PLC PLC
Combustion Chamber 100L 210L 330L 560L
Internal Dimensions 50x50x40cm 65x65x50cm 75x75x60cm 100x80x70cm
Secondary Chamber 50L 110L 180L 280L
Smoke Filter Chamber Yes Yes Yes Yes
Feed Mode Manual Manual Manual Manual
Voltage 220V 220V 220V 220V
Power 0.5Kw 0.5Kw 0.5Kw 0.7Kw
Oil Consumption (kg/hour) 5.4–12.6 7.8–16.3 10.2–20 12.1–24
Gas Consumption (m3/hour) 6.2–11.4 8–15.7 9.8–20 9.9–26.1
Temperature Monitor Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes
Oil Tank 100L 100L 100L 100L
Feed Door 30x30cm 45x40cm 55x50cm 70x55cm
Chimney 3Meter 3Meter 5Meter 5Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800℃–1000℃ 800℃–1000℃ 800℃–1000℃ 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 1500kg 2200kg 3000kg 4500kg
External Dimensions 140x90x120cm 160x110x130cm 175x120x140cm 230x130x155cm
Items/Model TS100(PLC) TS150(PLC) TS300(PLC) TS500(PLC)
Burn Rate (Average) 100 kg/hour 150 kg/hour 300 kg/hour 500 kg/hour
Control Mode PLC Auto. PLC Auto. PLC Auto. PLC Auto.
Combustion Chamber 1200L 1500L 2000L 3000L
Internal Dimensions 120x100x100cm 150x100x100cm 170x120x100cm 210x120x120cm
Secondary Chamber 600L 750L 1000L 1500L
Smoke Filter Chamber Dry Scrubber Dry Scrubber Dry Scrubber Dry Scrubber
Feed Mode Manual Manual Manual Manual
Voltage 220V 220V 220V 220V
Power 1.38Kw 1.69Kw 2.57Kw 4.88Kw
Diesel Oil Consumption (kg/hour) Ave.20.4 Ave.24.2 Ave.33 Ave.44
Natural Gas Consumption (m3n/hour) Ave.24.5 Ave.29 Ave.39.6 Ave.52.8
Temperature Monitor Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes
Oil Tank 200L 300L 500L 500L
Chimney 10Meter 10Meter 14Meter 14Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800℃–1000℃ 800℃–1000℃ 800℃–1000℃ 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 6000kg 8500kg 11000kg 16000kg
External Dimensions 260x150x180cm 300x160x190cm 400x210x300cm 450x210x300cm

CE and ISO Certification Pass Incinerators

2021-03-02

Laboratory Waste Incinerator Sierra Leone

medical waste incineration,hazardous waste incinerators

Items/Model TS30(PLC)

Brand/Code HICLOVER/N718
Burn Rate Average 30 kg/hour
Feed Capacity Average 60kg per feeding
Control Mode PLC(Programmable Logic Controller Incinerator)
Combustion Chamber 330L
Internal Dimensions 75x75x60cm
Secondary Chamber 180L
Smoke Filter Chamber Yes
Feed Mode Manual Feeding
Voltage 220V
Power 0.5Kw
Oil Consumption (kg/hour) Average 13.3
Gas Consumption (N.G, m3n/Hour) Average 16
Gas Consumption (L.P.G, m3n/Hour) Average 11.7
Temperature Monitor Four Digital Display
Temperature Protection Yes
Oil Tank 100L or More(Optional)
Feed Door 55x50cm
Chimney 5Meter or More(Optional)
Chimney Type Stainless Steel
1st. Chamber Temperature 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃
Residency Time 2.0 Sec.
Gross Weight 4000kg
External Dimensions 175x120x140cm

HICLOVER Solution for Fighting COVID-19, with ISO9001:2015/CE(2006/42/EC,2014/30/EU) Certification.
1. Medical Waste Incinerator(Containerized Mobile Incinerator｜Top Loading Incinerator)
2. Auto Roll Air Filter for Clean Room(Air Purification)

Nanjing Clover Medical Technology Co.,Ltd.
Tel: +86-25-8461 0201
Mobile: +86-138139 31455
WhatsApp: 008613813931455
WhatsApp: 008615380948599
Twitter ID: @hiclovercom
Wechat: 008613813931455 (ID: hiclovercom)
Wechat: +8615380948599 (ID: wasteincinerator)

Website1: www.hiclover.com
Website2: www.clover-incinerator.com
Email1: [email protected]
Email2: [email protected]
Email3: [email protected]
Email4: [email protected]

Supply of a hospital waste / general waste incinerator, including auxiliaries, packaging and transport to Sierra Leone (FCA Incoterms) as well as installation and commissioning supervision.
The name plate capacities and attribute requirements are detailed below:
Retort type diesel fuelled incinerator rated at 120kg/h.
Primary and secondary burners with temperature range 850 to 1000 degrees Celsius.
Top mounted chimney, lined and painted externally with high temperature corrosion protection.
Burners and fan controller to be included. The incinerator should run automatically with minimal human intervention to operate.
Stack emissions shall be within the legislative requirements of Sierra Leone as a minimum.
Provision for any special tooling requirements.
Provision of 1 year of spares for services and maintenance.
Provision of any critical or long lead item spares. Human Cremation Equipment

The scope of service additional to the supply of the incinerator is as follows:
Provision for packaging the incinerator components into an ISO shipping container, including lashing as required and transporting to the nearest sea port (Basetek can do this if necessary, though).
FCA shipping to Sierra-Leone, Free-town (again Basetek can do this if necessary).
Supervision of installation and commissioning of the incinerator on site in Sierra Leone.
Flight costs to site.
Personnel Protective Equipment.

The following items are excluded from the scope of supply and services:
Transport of the incinerator equipment from Free-town to Sierra Leone Site
Customs clearance and duties.
Meals and accommodation shall be provided for while on site.
Passenger transport from Lungi (Freetown airport) to Sierra Leone site and return trip.
Marine insurances.

HICLOVER Incinerator/Parts Range Main Feature
Medical Waste Incinerators HICLOVER 10-500kgs/Hr.Double Combustion Chambers
Single Combustion Chamber Small, Cheap,10-20kgs/Hr.
Three Combustion Chambers(Optional) 3 Chambers for high risk waste
Pet Cremation Equipment For Pet(small/big) Cremation Business
Animal Incineration Equipment For other animal incineration

Feature
Specification

Incinerator
Auxiliary Fuel – Diesel

Type of Burner operation-Monoblock fully automatic burners

Primary Chamber

Type
Static Solid Hearth

Material of Construction
Mild Steel

Ash Removal
Manual

Waste feeding system
Manual

Secondary Chamber

Material of Construction
Mild Steel

Burner

Type
Monoblock fully automatic oil fired

Fuel
LP

Chimney

Material of Construction
Stainless Steel – 12 feet

Control Panel
Automatic temperature control

Hourly destruction capacity (kg/hr)
5 – 10

Volume of primary chamber (ft3)
1.5

Volume of secondary chamber (ft3)
2.5

Fuel consumption (kg/hr)
4 – 5

Basic dimensions (diameter x height in feet)
3 x 5

Weight (tons)
1

Burners
2

Power supply
230V, 50Hz

Items/Model TS10(PLC) TS20(PLC) TS30(PLC) TS50(PLC)
Brand HICLOVER HICLOVER HICLOVER HICLOVER
Burn Rate (Average) 10 kg/hour 20 kg/hour 30 kg/hour 50 kg/hour
Feed Capacity(Average) 20kg 40kg 60kg 100kg
Control Mode PLC PLC PLC PLC
Combustion Chamber 100L 210L 330L 560L
Internal Dimensions 50x50x40cm 65x65x50cm 75x75x60cm 100x80x70cm
Secondary Chamber 50L 110L 180L 280L
Smoke Filter Chamber Yes Yes Yes Yes
Feed Mode Manual Manual Manual Manual
Voltage 220V 220V 220V 220V
Power 0.5Kw 0.5Kw 0.5Kw 0.7Kw
Oil Consumption (kg/hour) 5.4–12.6 7.8–16.3 10.2–20 12.1–24
Gas Consumption (m3/hour) 6.2–11.4 8–15.7 9.8–20 9.9–26.1
Temperature Monitor Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes
Oil Tank 100L 100L 100L 100L
Feed Door 30x30cm 45x40cm 55x50cm 70x55cm
Chimney 3Meter 3Meter 5Meter 5Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800℃–1000℃ 800℃–1000℃ 800℃–1000℃ 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 1500kg 2200kg 3000kg 4500kg
External Dimensions 140x90x120cm 160x110x130cm 175x120x140cm 230x130x155cm
Items/Model TS100(PLC) TS150(PLC) TS300(PLC) TS500(PLC)
Burn Rate (Average) 100 kg/hour 150 kg/hour 300 kg/hour 500 kg/hour
Control Mode PLC Auto. PLC Auto. PLC Auto. PLC Auto.
Combustion Chamber 1200L 1500L 2000L 3000L
Internal Dimensions 120x100x100cm 150x100x100cm 170x120x100cm 210x120x120cm
Secondary Chamber 600L 750L 1000L 1500L
Smoke Filter Chamber Dry Scrubber Dry Scrubber Dry Scrubber Dry Scrubber
Feed Mode Manual Manual Manual Manual
Voltage 220V 220V 220V 220V
Power 1.38Kw 1.69Kw 2.57Kw 4.88Kw
Diesel Oil Consumption (kg/hour) Ave.20.4 Ave.24.2 Ave.33 Ave.44
Natural Gas Consumption (m3n/hour) Ave.24.5 Ave.29 Ave.39.6 Ave.52.8
Temperature Monitor Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes
Oil Tank 200L 300L 500L 500L
Chimney 10Meter 10Meter 14Meter 14Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800℃–1000℃ 800℃–1000℃ 800℃–1000℃ 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 6000kg 8500kg 11000kg 16000kg
External Dimensions 260x150x180cm 300x160x190cm 400x210x300cm 450x210x300cm

CE and ISO Certification Pass Incinerators

2021-03-02

Clinical waste incineration and hazardous waste incineration facility

Clinical waste incineration and hazardous waste incineration facility

Model YD-50C

Brand/Code HICLOVER/N1004
Burning Rate (kgs/Hour) Average 50 kgs/Hour
Feed Capacity (kgs) Average 80 kgs/feeding
Equipment Weight 2500 kgs
Primary Chamber (Liters) 400
Secondary Chamber (Liters) 140
External Dimensions (cm) 180x160x200
Internal Dimensions (cm) 70x70x85
Oil Tank(Liters) 150
Door Opening (cm) 45×55
Chimney (M) 5
Chimney Type Stainless Steel
Secondary Chamber YES
Mix-Combustion Chamber YES
Smoke Filter Chamber YES
Combustion Fuel Oil
Residency Time 2.0 Sec.
Temperature Monitoring YES
1st. Chamber Temperature 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃

mobile incinerator,municipal waste incineration

HICLOVER Solution for Fighting COVID-19, with ISO9001:2015/CE(2006/42/EC,2014/30/EU) Certification.
1. Medical Waste Incinerator(Containerized Mobile Incinerator｜Top Loading Incinerator)
2. Auto Roll Air Filter for Clean Room(Air Purification)

Nanjing Clover Medical Technology Co.,Ltd.
Tel: +86-25-8461 0201
Mobile: +86-138139 31455
WhatsApp: 008613813931455
WhatsApp: 008615380948599
Twitter ID: @hiclovercom
Wechat: 008613813931455 (ID: hiclovercom)
Wechat: +8615380948599 (ID: wasteincinerator)

Website1: www.hiclover.com
Website2: www.clover-incinerator.com
Email1: [email protected]
Email2: [email protected]
Email3: [email protected]
Email4: [email protected]

HICLOVER Incinerator/Parts Range Main Feature
Medical Waste Incinerators HICLOVER 10-500kgs/Hr.Double Combustion Chambers
Single Combustion Chamber Small, Cheap,10-20kgs/Hr.
Three Combustion Chambers(Optional) 3 Chambers for high risk waste
Pet Cremation Equipment For Pet(small/big) Cremation Business
Animal Incineration Equipment For other animal incineration
Items/Model TS10(PLC) TS20(PLC) TS30(PLC) TS50(PLC)
Brand HICLOVER HICLOVER HICLOVER HICLOVER
Burn Rate (Average) 10 kg/hour 20 kg/hour 30 kg/hour 50 kg/hour
Feed Capacity(Average) 20kg 40kg 60kg 100kg
Control Mode PLC PLC PLC PLC
Combustion Chamber 100L 210L 330L 560L
Internal Dimensions 50x50x40cm 65x65x50cm 75x75x60cm 100x80x70cm
Secondary Chamber 50L 110L 180L 280L
Smoke Filter Chamber Yes Yes Yes Yes
Feed Mode Manual Manual Manual Manual
Voltage 220V 220V 220V 220V
Power 0.5Kw 0.5Kw 0.5Kw 0.7Kw
Oil Consumption (kg/hour) 5.4–12.6 7.8–16.3 10.2–20 12.1–24
Gas Consumption (m3/hour) 6.2–11.4 8–15.7 9.8–20 9.9–26.1
Temperature Monitor Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes
Oil Tank 100L 100L 100L 100L
Feed Door 30x30cm 45x40cm 55x50cm 70x55cm
Chimney 3Meter 3Meter 5Meter 5Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800℃–1000℃ 800℃–1000℃ 800℃–1000℃ 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 1500kg 2200kg 3000kg 4500kg
External Dimensions 140x90x120cm 160x110x130cm 175x120x140cm 230x130x155cm
Items/Model TS100(PLC) TS150(PLC) TS300(PLC) TS500(PLC)
Burn Rate (Average) 100 kg/hour 150 kg/hour 300 kg/hour 500 kg/hour
Control Mode PLC Auto. PLC Auto. PLC Auto. PLC Auto.
Combustion Chamber 1200L 1500L 2000L 3000L
Internal Dimensions 120x100x100cm 150x100x100cm 170x120x100cm 210x120x120cm
Secondary Chamber 600L 750L 1000L 1500L
Smoke Filter Chamber Dry Scrubber Dry Scrubber Dry Scrubber Dry Scrubber
Feed Mode Manual Manual Manual Manual
Voltage 220V 220V 220V 220V
Power 1.38Kw 1.69Kw 2.57Kw 4.88Kw
Diesel Oil Consumption (kg/hour) Ave.20.4 Ave.24.2 Ave.33 Ave.44
Natural Gas Consumption (m3n/hour) Ave.24.5 Ave.29 Ave.39.6 Ave.52.8
Temperature Monitor Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes
Oil Tank 200L 300L 500L 500L
Chimney 10Meter 10Meter 14Meter 14Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800℃–1000℃ 800℃–1000℃ 800℃–1000℃ 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 6000kg 8500kg 11000kg 16000kg
External Dimensions 260x150x180cm 300x160x190cm 400x210x300cm 450x210x300cm

CE and ISO Certification Pass Incinerators

2021-03-02

Types of waste Generated in the health facility

HICLOVER Incinerator/Parts Range

Medical Waste Incinerators HICLOVER 10-500kgs/Hr.Double Combustion Chambers
Single Combustion Chamber Small, Cheap,10-20kgs/Hr.
Three Combustion Chambers(Optional) 3 Chambers for high risk waste
Pet Cremation Equipment For Pet(small/big) Cremation Business
Animal Incineration Equipment For other animal incineration

Temperature Control, Primary and Secondary
Stoking tools
Stainless Steel Spark Screen
Primary Chamber Door Locking System


HICLOVER Solution for Fighting COVID-19, with ISO9001:2015/CE(2006/42/EC,2014/30/EU) Certification.
1. Medical Waste Incinerator(Containerized Mobile Incinerator｜Top Loading Incinerator)
2. Auto Roll Air Filter for Clean Room(Air Purification)

Nanjing Clover Medical Technology Co.,Ltd.
Tel: +86-25-8461 0201
Mobile: +86-138139 31455
WhatsApp: 008613813931455
WhatsApp: 008615380948599
Twitter ID: @hiclovercom
Wechat: 008613813931455 (ID: hiclovercom)
Wechat: +8615380948599 (ID: wasteincinerator)

Website1: www.hiclover.com
Website2: www.clover-incinerator.com
Email1: [email protected]
Email2: [email protected]
Email3: [email protected]
Email4: [email protected]

Items/Model TS10(PLC) TS20(PLC) TS30(PLC) TS50(PLC)
Brand HICLOVER HICLOVER HICLOVER HICLOVER
Burn Rate (Average) 10 kg/hour 20 kg/hour 30 kg/hour 50 kg/hour
Feed Capacity(Average) 20kg 40kg 60kg 100kg
Control Mode PLC PLC PLC PLC
Combustion Chamber 100L 210L 330L 560L
Internal Dimensions 50x50x40cm 65x65x50cm 75x75x60cm 100x80x70cm
Secondary Chamber 50L 110L 180L 280L
Smoke Filter Chamber Yes Yes Yes Yes
Feed Mode Manual Manual Manual Manual
Voltage 220V 220V 220V 220V
Power 0.5Kw 0.5Kw 0.5Kw 0.7Kw
Oil Consumption (kg/hour) 5.4–12.6 7.8–16.3 10.2–20 12.1–24
Gas Consumption (m3/hour) 6.2–11.4 8–15.7 9.8–20 9.9–26.1
Temperature Monitor Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes
Oil Tank 100L 100L 100L 100L
Feed Door 30x30cm 45x40cm 55x50cm 70x55cm
Chimney 3Meter 3Meter 5Meter 5Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800℃–1000℃ 800℃–1000℃ 800℃–1000℃ 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 1500kg 2200kg 3000kg 4500kg
External Dimensions 140x90x120cm 160x110x130cm 175x120x140cm 230x130x155cm

Prefabricated Incinerator with a concrete base and chain link fence.The incinerator should be portable, very easy to install, allow for re-location, fit in small space with a chimney length of 4m to drive smoke away to safe heights and also cause current flow of fresh air to drive moisture out of the rubbish such that the bad odour from sanitary pads is removed and the waste is dried automatically. The incinerator should be made of a non-rusting material such as stainless steel of 4mm gauge. It should not require an extra heat source, but use the heat generated from burning of the solid waste as its major energy source. This incinerator should be capable of raising temperature to its maximum within three minutes and the heat losses kept to the minimum.Average Temperature
Average Temperature; 850 degrees Cent grade (As per Ministry of Health)
Capacity Capacity; 60 Liters, Auto combustion/nonfuel assisted
Destruction rate 30 liters per hour, waste reduction up to 95%volume
Batch Load 5Kgs per load
Life Span Life span; minimum 10 years

Items/Model TS100(PLC) TS150(PLC) TS300(PLC) TS500(PLC)
Burn Rate (Average) 100 kg/hour 150 kg/hour 300 kg/hour 500 kg/hour
Control Mode PLC Auto. PLC Auto. PLC Auto. PLC Auto.
Combustion Chamber 1200L 1500L 2000L 3000L
Internal Dimensions 120x100x100cm 150x100x100cm 170x120x100cm 210x120x120cm
Secondary Chamber 600L 750L 1000L 1500L
Smoke Filter Chamber Dry Scrubber Dry Scrubber Dry Scrubber Dry Scrubber
Feed Mode Manual Manual Manual Manual
Voltage 220V 220V 220V 220V
Power 1.38Kw 1.69Kw 2.57Kw 4.88Kw
Diesel Oil Consumption (kg/hour) Ave.20.4 Ave.24.2 Ave.33 Ave.44
Natural Gas Consumption (m3n/hour) Ave.24.5 Ave.29 Ave.39.6 Ave.52.8
Temperature Monitor Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes
Oil Tank 200L 300L 500L 500L
Chimney 10Meter 10Meter 14Meter 14Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800℃–1000℃ 800℃–1000℃ 800℃–1000℃ 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 6000kg 8500kg 11000kg 16000kg
External Dimensions 260x150x180cm 300x160x190cm 400x210x300cm 450x210x300cm

CE and ISO Certification Pass Incinerators

2021-03-02

Poultry Incinerator Design for Pets Cremation Business

Model A1500

Brand/Product Code HICLOVER/N1134
Burning Rate Average 50 kgs/hour
Feed Capacity Average 150 kgs/feeding
Primary Combustion Chamber 1500 Liters
Secondary Combustion Chamber 500 Liters
Mix Combustion Chamber Yes
Smoke Filter Chamber Yes
Feed Mode Manual
Voltage 220V/380V
Fuel Type Diesel Oil/ Natural Gas/LPG
Burner Italy Original
Oil Consumption (Diesel Oil) Average 34 kg/hour
Gas Consumption (Natural Gas) Average 41 m3n/hour
Internal Dimensions 150 x 100 x 96cm (primary chamber)
External Dimensions 240 x 170 x 380cm (without chimney)
Temperature Monitor Yes
Oil Tank Capacity(if oil fuel) 300 Liters
Door Opening 59 x 81cm
Chimney Length 10.0 Meters
Chimney Type Stainless Steel
Equipment Gross Weight 7500 kgs
Operation Technical Specifications
Primary Chamber Temperature 800℃–1000℃
Secondary Chamber Temperature 1000℃-1200℃
Residency Time 2.0 Sec.
Burning Efficiency ＞98%
Waste Lower Calorific Power 3000Kcal

Pet Incinerator,Best incinerator manufacturers
HICLOVER Solution for Fighting COVID-19, with ISO9001:2015/CE(2006/42/EC,2014/30/EU) Certification.
1. Medical Waste Incinerator(Containerized Mobile Incinerator｜Top Loading Incinerator)
2. Auto Roll Air Filter for Clean Room(Air Purification)

Nanjing Clover Medical Technology Co.,Ltd.
Tel: +86-25-8461 0201
Mobile: +86-138139 31455
WhatsApp: 008613813931455
WhatsApp: 008615380948599
Twitter ID: @hiclovercom
Wechat: 008613813931455 (ID: hiclovercom)
Wechat: +8615380948599 (ID: wasteincinerator)

Website1: www.hiclover.com
Website2: www.clover-incinerator.com
Email1: sales
Email2: hicloversales
Email3: sales
Email4: cloverincinerator

HICLOVER Incinerator/Parts Range Main Feature
Medical Waste Incinerators HICLOVER 10-500kgs/Hr.Double Combustion Chambers
Single Combustion Chamber Small, Cheap,10-20kgs/Hr.
Three Combustion Chambers(Optional) 3 Chambers for high risk waste
Pet Cremation Equipment For Pet(small/big) Cremation Business
Animal Incineration Equipment For other animal incineration
Items/Model TS10(PLC) TS20(PLC) TS30(PLC) TS50(PLC)
Brand HICLOVER HICLOVER HICLOVER HICLOVER
Burn Rate (Average) 10 kg/hour 20 kg/hour 30 kg/hour 50 kg/hour
Feed Capacity(Average) 20kg 40kg 60kg 100kg
Control Mode PLC PLC PLC PLC
Combustion Chamber 100L 210L 330L 560L
Internal Dimensions 50x50x40cm 65x65x50cm 75x75x60cm 100x80x70cm
Secondary Chamber 50L 110L 180L 280L
Smoke Filter Chamber Yes Yes Yes Yes
Feed Mode Manual Manual Manual Manual
Voltage 220V 220V 220V 220V
Power 0.5Kw 0.5Kw 0.5Kw 0.7Kw
Oil Consumption (kg/hour) 5.4–12.6 7.8–16.3 10.2–20 12.1–24
Gas Consumption (m3/hour) 6.2–11.4 8–15.7 9.8–20 9.9–26.1
Temperature Monitor Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes
Oil Tank 100L 100L 100L 100L
Feed Door 30x30cm 45x40cm 55x50cm 70x55cm
Chimney 3Meter 3Meter 5Meter 5Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800℃–1000℃ 800℃–1000℃ 800℃–1000℃ 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 1500kg 2200kg 3000kg 4500kg
External Dimensions 140x90x120cm 160x110x130cm 175x120x140cm 230x130x155cm
Items/Model TS100(PLC) TS150(PLC) TS300(PLC) TS500(PLC)
Burn Rate (Average) 100 kg/hour 150 kg/hour 300 kg/hour 500 kg/hour
Control Mode PLC Auto. PLC Auto. PLC Auto. PLC Auto.
Combustion Chamber 1200L 1500L 2000L 3000L
Internal Dimensions 120x100x100cm 150x100x100cm 170x120x100cm 210x120x120cm
Secondary Chamber 600L 750L 1000L 1500L
Smoke Filter Chamber Dry Scrubber Dry Scrubber Dry Scrubber Dry Scrubber
Feed Mode Manual Manual Manual Manual
Voltage 220V 220V 220V 220V
Power 1.38Kw 1.69Kw 2.57Kw 4.88Kw
Diesel Oil Consumption (kg/hour) Ave.20.4 Ave.24.2 Ave.33 Ave.44
Natural Gas Consumption (m3n/hour) Ave.24.5 Ave.29 Ave.39.6 Ave.52.8
Temperature Monitor Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes
Oil Tank 200L 300L 500L 500L
Chimney 10Meter 10Meter 14Meter 14Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800℃–1000℃ 800℃–1000℃ 800℃–1000℃ 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 6000kg 8500kg 11000kg 16000kg
External Dimensions 260x150x180cm 300x160x190cm 400x210x300cm 450x210x300cm

CE and ISO Certification Pass Incinerators

2021-02-28

Garbage Incinerator TS150 PLC Mobile Type

Items/Model HICLOVER TS150(PLC) (Mobile Type)

N1155

mobile incinerator
Principle Waste Incineration Treatment,

trash incinerator
Burn Rate Average 150 kg/hour
Feed Capacity Average 150kg/feeding
Control Mode PLC(Programmable Logic Controller Incinerator)
Combustion Chamber 1200L
Internal Dimensions 120x100x100cm
Secondary Chamber 600L
Smoke Filter Chamber Yes(Dry Scrubber)
Feed Mode Manual
Voltage 220V
Power 0.9Kw
Oil Consumption (kg/hour) average 20.4
Gas Consumption (m3/hour) average 24.5
Temperature Monitor Digital Display
Temperature Protection Yes
Oil Tank 200L
Feed Door 80x60cm
Chimney 5Meter
Chimney Type Stainless Steel
1st. Chamber Temperature 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃
Residency Time 2.0 Sec.
Gross Weight 7000kg
External Dimensions 260x150x180cm(Incinerator)

Phone: +86-13813931455(whatsapp/wechat)
Website: http://www.hiclover.com/
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.

HICLOVER Incinerator/Parts Range Main Feature
Medical Waste Incinerators HICLOVER 10-500kgs/Hr.Double Combustion Chambers
Single Combustion Chamber Small, Cheap,10-20kgs/Hr.
Three Combustion Chambers(Optional) 3 Chambers for high risk waste
Pet Cremation Equipment For Pet(small/big) Cremation Business
Animal Incineration Equipment For other animal incineration
Items/Model TS100(PLC) TS150(PLC) TS300(PLC) TS500(PLC)
Burn Rate (Average) 100 kg/hour 150 kg/hour 300 kg/hour 500 kg/hour
Control Mode PLC Auto. PLC Auto. PLC Auto. PLC Auto.
Combustion Chamber 1200L 1500L 2000L 3000L
Internal Dimensions 120x100x100cm 150x100x100cm 170x120x100cm 210x120x120cm
Secondary Chamber 600L 750L 1000L 1500L
Smoke Filter Chamber Dry Scrubber Dry Scrubber Dry Scrubber Dry Scrubber
Feed Mode Manual Manual Manual Manual
Voltage 220V 220V 220V 220V
Power 1.38Kw 1.69Kw 2.57Kw 4.88Kw
Diesel Oil Consumption (kg/hour) Ave.20.4 Ave.24.2 Ave.33 Ave.44
Natural Gas Consumption (m3n/hour) Ave.24.5 Ave.29 Ave.39.6 Ave.52.8
Temperature Monitor Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes
Oil Tank 200L 300L 500L 500L
Chimney 10Meter 10Meter 14Meter 14Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800℃–1000℃ 800℃–1000℃ 800℃–1000℃ 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 6000kg 8500kg 11000kg 16000kg
External Dimensions 260x150x180cm 300x160x190cm 400x210x300cm 450x210x300cm

CE Certification Pass

HICLOVER Solution for Fighting COVID-19 with CE Certification.

1. Medical Waste Incinerator(Containerized Mobile Incinerator｜Top Loading Incinerator)

2. Auto Roll Air Filter for Clean Room

2021-02-28

Incinerator design for hospitals

Items/Model TS300(PLC)

Principle Solid Waste Incineration Treatment
Burn Rate Average 300 kg/hour
Feed Capacity Average 400kg/feeding
Control Mode PLC(Programmable Logic Controller Incinerator)
Combustion Chamber 2000L
Internal Dimensions 170x120x100cm
Secondary Chamber 1000L
Smoke Filter Chamber Yes
Feed Mode Manual
Voltage 220V
Power 2.0Kw
Oil Consumption (kg/hour) Average 38(DO)
Gas Consumption (m3/hour) Average 45.6(NG)
Temperature Monitor Digital Display
Temperature Protection Yes
Oil Tank 200L
Feed Door 80x60cm
Chimney 10Meter
Chimney Type Stainless Steel
1st. Chamber Temperature 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃
Residency Time 2.0 Sec.
Gross Weight 11000kg
External Dimensions 400x210x300cm(without chimney)

Phone: +86-13813931455(whatsapp/wechat)
Website: http://www.hiclover.com/
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.

HICLOVER Incinerator/Parts Range Main Feature
Medical Waste Incinerators HICLOVER 10-500kgs/Hr.Double Combustion Chambers
Single Combustion Chamber Small, Cheap,10-20kgs/Hr.
Three Combustion Chambers(Optional) 3 Chambers for high risk waste
Pet Cremation Equipment For Pet(small/big) Cremation Business
Animal Incineration Equipment For other animal incineration
Items/Model TS100(PLC) TS150(PLC) TS300(PLC) TS500(PLC)
Burn Rate (Average) 100 kg/hour 150 kg/hour 300 kg/hour 500 kg/hour
Control Mode PLC Auto. PLC Auto. PLC Auto. PLC Auto.
Combustion Chamber 1200L 1500L 2000L 3000L
Internal Dimensions 120x100x100cm 150x100x100cm 170x120x100cm 210x120x120cm
Secondary Chamber 600L 750L 1000L 1500L
Smoke Filter Chamber Dry Scrubber Dry Scrubber Dry Scrubber Dry Scrubber
Feed Mode Manual Manual Manual Manual
Voltage 220V 220V 220V 220V
Power 1.38Kw 1.69Kw 2.57Kw 4.88Kw
Diesel Oil Consumption (kg/hour) Ave.20.4 Ave.24.2 Ave.33 Ave.44
Natural Gas Consumption (m3n/hour) Ave.24.5 Ave.29 Ave.39.6 Ave.52.8
Temperature Monitor Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes
Oil Tank 200L 300L 500L 500L
Chimney 10Meter 10Meter 14Meter 14Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800℃–1000℃ 800℃–1000℃ 800℃–1000℃ 800℃–1000℃
2nd. Chamber Temperature 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃ 1000℃-1200℃
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 6000kg 8500kg 11000kg 16000kg
External Dimensions 260x150x180cm 300x160x190cm 400x210x300cm 450x210x300cm

Controlled hygienic, mechanical or automatic feeding methods must not negatively influence the air supply and temperature in the primary and secondary chambers of the incinerator.
“Each unit shall include a diesel fuel storage tank of sufficient capacity to enable operation of the unit for 5 working days of 10 hours each.
• The unit shall include a pumping system and lines to supply the burners from the tank and the diesel-electric generator. The pumping system will have two pumps in parallel for redundancy.
• The supply lines will be fabricated from steel tubing and adequately protected and supported against damage during operations and include shutoff valves for each line.
• The unit shall be equipped with a fuel meter.
”
“The waste incinerators shall be designed for the following electricity supply:
• 3 phase, 4 wire, 415 V a.c. ±10%, 50 Hz ±3%
• 3 phase 4 wire, 220 V a.c. ±10%, 60 Hz ±3%
Incinerators must be able to support different power sources (PV solar system , diesel Electric generator , local or compound mini-scale grid)

CE Certification Pass

HICLOVER Solution for Fighting COVID-19 with CE Certification.

1. Medical Waste Incinerator(Containerized Mobile Incinerator｜Top Loading Incinerator)

2. Auto Roll Air Filter for Clean Room

2021-02-24
