Medical waste incinerator 100kgs Model TS100

incinerator manufacturer,medical incinerator,small scale incinerator,oil fired incinerator

Items/Model	TS100
Burn Rate	Average 100 kg/hour
Feed Capacity	Average 200 kg/feed
Control Mode	PLC
Combustion Chamber	1200L
Internal Dimensions	120x100x100cm
Secondary Chamber	600L
Smoke Filter Chamber	Yes
Feed Mode	Manual
Voltage	220V
Power	0.7Kw
Oil Consumption (kg/hour)	14–28
Gas Consumption (m3/hour)	10–32.2
Temperature Monitor	Yes
Temperature Protection	Yes
Oil Tank	200L
Feed Door	80x60cm
Chimney	10Meter
Chimney Type	Stainless Steel
1st. Chamber Temperature	800℃–-1000℃
2nd. Chamber Temperature	1000℃-1200℃
Residency Time	2.0 Sec.
Gross Weight	6000kg
External Dimensions	260x150x180cm
