Containerized Incinerator is one type of mobile incinerator. we build the incinerator and mounted the incinerator into shipping container(20′ container or 40′ container), with necessary Basic work, such as flooring, lighting, wiring, etc.
Containerized Incinerator is one type of mobile incinerator. we build the incinerator and mounted the incinerator into shipping container(20′ container or 40′ container), with necessary Basic work, such as flooring, lighting, wiring, etc.
This model is small-scale waste incineration equipment for small waste output. Construction
is dual/double combustion chamber with 02 units oil burner, batch load incineration equipment.
Waste feed chamber is 1800Liters (1.8m3, TS250 PLC). Primary & Secondary combustion chambers
and smoke filter chamber. Batch load on the bottom of chamber. Incinerator PLC panel control suit for local operation.
Main Product List per 01 set
Primary Combustion Chamber
Secondary Combustion Chamber
Smoke Filter Chamber
Incinerator PLC Control Case
Chimney:10.0Meters
*(upgrade to Stainless Steel, free cost)
Italy oil/gas burner: 02 units
Oil Tank (if oil fuel): 300Liters
Items/Model
TS200(PLC)
insertpic 2
insertpic fc90
Principle
Solid Waste Incineration Treatment
Burn Rate
Average 250 kg/hour
Feed Capacity
Average 350kg/feeding
Control Mode
PLC(Programmable Logic Controller Incinerator)
Combustion Chamber
1800L
Internal Dimensions
150x110x110cm
Secondary Chamber
750L
Smoke Filter Chamber
Yes
Feed Mode
Manual
Voltage
220V
Power
0.9Kw
Oil Consumption (kg/hour)
Average 28
Gas Consumption (m3/hour)
Average 33.6
Temperature Monitor
Digital Display
Temperature Protection
Yes
Oil Tank
300L
Feed Door
80x60cm
Chimney
10Meter
Chimney Type
Stainless Steel
1st. Chamber Temperature
800℃–1000℃
2nd. Chamber Temperature
1000℃-1200℃
Residency Time
2.0 Sec.
Gross Weight
8500kg
External Dimensions
300x160x190cm
Burner operation should be Automatic On/Off
Fuel : diesel
The supplier must provide necessary information for the best of the installation
This incinerator with “PYROLYTIC” combustion must have:
;
· Refractory concrete :
§ . Thickness : ≥100 mm
§ . Nature: 42% of Al203
· Insulate in fibrous panels :
§ . Thickness: ≥75 mm
· Nature: Calcium silicate.
* Burner of lighting of waste, with fuel, standard mono-bloc casting guiding plunging flame, lighting and safety of electronic ignition, permanent ventilation, electromagnetic sluice gate of regulation and isolating valve.
* Plate of combustion in Carborundum, avoiding the fixing of glass and slags.
A chamber of post combustion of gases
* A burner of combustion of gases,
* A device of injection of air allowing a total recombustion of gases,
* A device of air inlet of cooling of waste gases,
* A sheath of evacuation of the gases burnt.
* Carcass in strong sheet steel with support of connection.
Waste Incineration Treatment Diesel Oil type Model TS150
Main Parts List as below:
Primary combustion chamber
Secondary combustion chamber
smoke filter chamber
incinerator PLC control case
chimney, 10meters, stainless steel
Italy Oil fule burner
oil tank 300liters
with full spare parts: oil burner, air blower, temperature thermocouple
Waste is thermally decomposed in the primary chamber at temperatures of 800 °C +. The resulting gaseous products are completely oxidized in the secondary chamber at higher temperatures with sufficient resident time. Other specifications are as follows. A combustion chamber of waste:
* Perfectly tight door for the manual loading of waste. The loading should be Manual, Batch Load
* A burner of lighting which the use is limited to the ignition of waste.
* Frontage of loading with door seals gone up on hinges, wheel of screw plug, flexible joint, and stuffing insulating out of refractory.
* The insulation of the combustion chamber should be composed of refractory bricks, having a high content of aluminum and insulates bricks in order to assure a minimum temperature on the outside sheet metal.
Waste is thermally decomposed in the primary chamber at temperatures of 800 °C +. The resulting gaseous products are completely oxidized in the secondary chamber at higher temperatures with sufficient resident time. Other specifications are as follows. A combustion chamber of waste:
* Perfectly tight door for the manual loading of waste. The loading should be Manual, Batch Load
* A burner of lighting which the use is limited to the ignition of waste.
* Frontage of loading with door seals gone up on hinges, wheel of screw plug, flexible joint, and stuffing insulating out of refractory.
* The insulation of the combustion chamber should be composed of refractory bricks, having a high content of aluminum and insulates bricks in order to assure a minimum temperature on the outside sheet metal.
Medium Unit – to handle an average waste production of 500 kg/day.Minimum load capacity: 600 kg.Maximum load capacity: 1,000 kg.Nominal burning rate: 55-80 kg/hr (= 440 640kg range per 8hour day).
We supply Double Chamber Incinerator with primary chamber size average 1570Liters and burnning rate 50kgs per hour,100kgs per hour,150kgs per hour,200kgs per hour.
the incinerators are now ready for shipping.
